Compact Lip Seal 1H3
Compact lip seal for small fitting areas in hydraulic applications.
Application Range
Pressure: ≤ 400 bar
Temperature HFA-, HFB-, HFC-liquids: ≤ +40 °C
Temperature mineral oils: -35 °C / +105 °C
Sliding Speed: ≤ 0,5 m/s
Standard Material: PUR
Other materials are available for very high or very low operating temperatures. For detailled information, please look at the specific PDF catalogue or contact our application engineers.
Load product catalog
Are you missing materials or dimensions?
Feel free to contact us!
Our sealing experts will be happy to advise you!
Filter
| d [mm] | D [mm] | H [mm] | L [mm] | |
|---|---|---|---|---|
| Min: | ||||
| Max: |
| Material selection | |
|---|---|
| Material: | |
| Material No. |
| Profile | d [mm] | D [mm] | H [mm] | L [mm] | Material | Mat. No. | V | Quantity |
|---|
